FV-FWR7202 – 4G-LTE Wireless VoIP Router

142,00 + IVA

Descrizione

Wireless VoIP Router – FWR7202

1 WAN and 4 LAN 100 BASE-T, 2 FXS, 802.11 b/g/n 2T2R

2.4GHz (IEEE802.11 b/g/n) Unlicensed Band & Licensed 4G-LTE



Ultra-Compact Design, Wide Coverage of Communication



PESQ 4.3, Advanced Acoustic Performance







Product Features



VoIP SoC Audio Code
• CPU: MIPS Single-core 600MHz • G.711 (A/u), PAMS>4.3

• G.729A/AB, PAMS>3.7

• T.30 FAX with G.711

• Real time FAX over IP via T.38

• Adaptive Jitter Buffer

• Voice Activity Detection

• Comfort Noise Generation

• Echo Cancellation

RAM
• 64MB DDR RAM
Flash
• 16MB Flash
Operating System
• Linux 2.6.36
Power LTE Features
• AC/DC Adapter

AC Input: 100~240V, 50~60Hz

DC Output: 12V, 1.5A

• Four-Band TDD-LTE B38/B39/B40/B41

• Four-Band FDD-LTE B1/B3/ /B7/B8

• Dual-Band TD-SCDMA B34/B39

• Dual-Band UMTS/HSDPA/HSPA+ B1/B8

• GSM/GPRS/EDGE 900/1800MHz

• Uplink up to 50Mbps

• Downlink up to 100Mbps

• 2G/3G Fallback

Certificates I/O Interfaces
• FCC Part 15 Class B appoval

• CE certification

• RoHS compliance

• 1 RJ-45 for WAN port (Ethernet 1000 Base-T)

• 4 RJ-45 for LAN port (Ethernet 1000 Base-T)

• 2 RJ-11 for FXS port

• 1 SIM card port

• IEEE802.11 b/g/n



Wireless Management
• 802.11 b/g/n support

• 4 SSID

• Static WEP (64/128bit)

• Dynamic WEP (64/128bit)

• AES (CCMP/TKIP)

• MAC certification

• WEP certification

• WPA-PAK/WPA-PSK (2.0)

• WPA/WPA2

• AP Isolation and MBSSID AP Isolation

• WMM

• WDS

• WPS

• Station list

• Radius certification and billing

• MAC Filter (different from wired MAC Filter)

• Firmware Upgradeable

• Web Management Interface

• IVR-driven Management Interface

• Local and Remote Syslog (RFC3164)

• Auto Provisioning

• SNTP Time Synchronization

• Multi User Level

• SNMPv2

• TR069

• Telnet

• System Log: local log and remote log

Protocols Call Features
• SIP V2.0 (RFC 3261, 3262, 3263, 3264)

• Backward compatible with RFC2543

• Session timer (RFC4028)

• SDP (RFC2327)

• RTP/RTCP (RFC823/903)

• NAPTR for SIP URI lookup (RFC2915)

• STUN (RFC2030)

• ARP/RARP (RFC 826/903)

• SNTP (RFC 2030)

• DHCP/PPPoE

• HTTP Server for Web Management

• TFTP/HTTP for Auto Provisioning

• Message Waiting Indicator (RFC3842)

• DHCP Option Codes for SIP (RFC3361)

• DNS/DNS SRV (RFC1706 and RFC 2782)

• IEEE802.1Q VLAN/802.1p and IP DSCP



• 3-way conference

• Call hold

• Call forwarding

• Call Transfer

• Call waiting

• Caller ID and CWCID

• DTMF Relay: In-band, Out-band and SIP INFO

• QoS Layer 3

• Call Log

• CID/CWCID

• Dial Plan

• DTMF Mode: Inband, outband and SIP Info

Applications
• Support LTE

• Support NAT mode and Bridge mode

• Support DDNS

• MAC address cloning

• SIP proxy redundancy

• NAT Traversal by STUN

• Built-in Wired speed NAT Router

• DHCP Server and Client

• IP conflict detection

• Port forwarding and DMZ host

• 802.1Q VLAN/802.1p, DSCP, Rate Limiting

• VPN (PPTP,L2TP, IPSec) Passthrough

• SNTP

• IGMPv2

• Firewall (SYN Flooding, IP Spoofing, Smurf Attack, Ping of Death, DoS)



Environmental Size and Weight
• Operation Temperature: 0~50 Degree C

• Storage Temperature: -25~85 Degree C

• Relative Humidity: 10%~90% No Condensing

• 188mm (L) x 155mm (W) x 29mm (H)

• 350g (N.W)

Model Comparison

FWR7202 FWR7302 FWR8102 FWR9120H
FXS (RJ11) 2 2 2 ×
FXO × × × 2
Ethernet (RJ45) 5*10/100M Ethernet 5*10/100/1000M Ethernet 4*10/100M Ethernet 5*10/100/1000M Ethernet
2.4GHz Speed 300 Mbps 300 Mbps 300 Mbps 300 Mbps
5GHz Speed × 867 Mbps × 867 Mbps
4G-LTE × ×
USB × 1 × 1
MU-MIMO × × × ×
HNAT ×
